Description:
Corrosive Liquid Safety Cabinets |
All cabinets built to comply with FM, OSHA |
Designed to storage all Class 8 liquids |
Distinct safety signs and directions |
Fully-welded construction holds squareness for longer life, offering greater protection in a fire since air gaps are reduced. |
1.0mm(18 gauge) double walled steel with 40mm(1.5'') of insulating air space |
Three-point mutual locking system with high-strength stainless steel bullet latches |
50mm(2'') leak-proof sump to contain spills |
Continuous piano hinge doors to open 180 degree |
Welded shelf hangers interlock with shelf to offer maximum "no slip" stability…and no flimsy brackets to lose. |
Zinc lever lock. Two keys lockable. |
Dual vents with built-in flash arresters strategically placed at bottom and opposite top. |
Durable and chemical resistant, powder coat paint finish, inside and outside, retains high gloss look and minimizes the effect of corrosion and humidity. |
Build-in grounding connector(on outside side panel) for easy grounding. |
Minimal air-gaps provide better protection. |
Liquid-tight containment sump. |
Adjustable leveling feet for balancing on uneven surfaces |
Fail-safe clsoing mechanism ensures three-point latching systme works thr first time, every time. Double key set included for security. |
Highly visible warning lable" CORROSIVE SUBSTANCES". |
Full adjustable galvanised shelves. |
Plastics tray for corrosive liquid. |
Shelves and trays easily replaced if damaged. |
Applications:
SSL Corrosive Cabinets are used to store weak corrosive chemicals, Oxidising Acids, Organic And Mineral Acids . For Examples : hydrochloric acid, vitriol and nitric acid;Nitric, sulfuric, perchloric, phosphoric and chromic acids.
acetic, nutyric, formic, glacial acetic hydrochloric, mercaptoproprionic, proprionic, trifluoroacetic acids.
Specifications:
SSMB100030-Hazardous Material Storage Cabinets |
30-gallon |
1 Shelf , 2 plastics trays(Adjustable) |
2 Doors, Manual - Economy Model |
Ext. Sizes HxWxD(mm/in): 1120 x 1090 x 460mm/ 44x 43 x 18 in |
Int. Sizes HxWxD(mm/in): 940 x 1010 x 380mm/ 37 x 40 x 15 in |
Weight: 110 kgs / 242lbs |
Competitive Advantage:
SSL Corrosive Cabinets are used to store weak corrosive chemicals .
A separate polyethylene plastica tray for the bottom sump. The tray can be removed for easy cleaning of drips and leaks.
Can order special base with new 2 x channel skid base sump floors for outdoor applications. Many happy users in a wide range of demanding environments, such as mining, defence, heavy engineering shops, airport facilities, port facilities and many more.
